CCS1 & Type 1 to CCS2 & Type 2 Charging Adapter - AC+DC 2 in 1
A versatile 2-in-1 charging adapter that enables CCS2/Type 2 (European standard) EVs to charge at CCS1/Type 1 (North American standard) charging stations. Supports both AC (Type 1 to Type 2) and DC (CCS1 to CCS2) charging with high power capacity up to 400A DC and 80A AC.
⚡ Dual Charging Mode Support: Supports both AC and DC charging in one compact adapter. DC Fast Charging: CCS1 to CCS2 conversion with max current 400A and voltage range 500-1000VDC. AC Charging: Type 1 to Type 2 conversion with max current 80A and voltage range 110V-250VAC.
🔧 Premium Build Quality: T2 Copper Alloy with silver plating for optimal conductivity and durability. PC (Polycarbonate) shell with UL94 V0 flame retardant rating. High-quality silicon rubber sealing gasket for reliable sealing.
🛡️ Safety & Protection: Built-in dual temperature kill switch with automatic charging stop when adapter reaches 90°C. IP54 protection rating against dust and water splashes, suitable for outdoor use in various weather conditions.
🌡️ Wide Operating Range: Operating temperature from 30°C to 50°C, storage temperature from -30°C to 85°C. Reliable performance in diverse climate conditions.
✅ International Certifications: FCC Certified compliant with Federal Communications Commission standards. RoHS Compliant, free from hazardous substances and environmentally friendly.
Technical Specifications:
DC Charging (CCS1 to CCS2):
Max Current: 400A
Voltage Range: 500-1000VDC
AC Charging (Type 1 to Type 2):
Max Current: 80A
Voltage Range: 110V-250VAC
Materials & Protection:
Conductor: T2 Copper Alloy, silver plated
Shell: PC (UL94 V0)
Protection Rating: IP54
Temperature & Certifications:
Operating Temp: 30°C to 50°C
Storage Temp: -30°C to 85°C
Certifications: FCC, RoHS
Applications:
Travel between Europe and North America with your EV
Use CCS2/Type 2 EVs at CCS1/Type 1 charging infrastructure
Fleet vehicles operating across different regions
EV rental and car-sharing services with diverse charging networks
Ready to Charge Across Continents?
Get the perfect 2-in-1 adapter solution for seamless charging between North American and European standards.
